| Number of coal feeding ponits | 12 |
| Power of screw conveyor | 0.37 Kw |
| Single burner CV | 57600 Kcal |
| Coal powder particle size | ≤ 5 mm |
| Coal moisture content | ≤ 5% |
| Coal consumption at each buner | 5-12 Kg/h |
| Max. flow at single feeding point | 180 m3/h |
| Blower and crushing power | 4 Kw |
| Voltage | 380v/415 v |
| Auxiliary power supply | 24 v |
| Maximum working pressure | 0,5 bar |
| Operating temperature | -10 to 50 ºC |
